The SIMRAD HALO20 Radar offers a powerful mix of short and long-range detection, delivering precise target definition with minimal clutter. It also features MARPA target tracking and instant wake-up from standby mode.

The SIMRAD HALO20 Radar provides unrivaled short-to-mid-range performance with its pulse-compression technology, extending your view from the bow of your boat out to 24 nautical miles. It delivers a powerful mix of short and long-range detection, and provides precise target definition with minimal clutter. With features such as MARPA target tracking and instant wake-up from standby mode, the HALO20 radar enhances your situational awareness and on-water safety. It also includes modes for navigating through crowded waterways and contending with poor visibility. This compact 20-inch dome radar is easy to use and offers a comprehensive range of features to keep you safe on the water.

Features

  • 10W Pulse Compression
  • 24 nm range from a compact 20-inch dome
  • Unrivalled short range
  • Radiation safe
  • Easy operation with harbour, offshore and weather mode
  • MARPA target tracking
  • InstantOn™
  • Low Power Consumption
  • Guard Zones

(SIM000-14536-001)

Compliance FCC, CE, Industry Canada, RCM (C-Tick), IEC60945, IEC60950 Electrical Safety
Power Consumption max. 20W, typical 18W
Recommended Fuse Rating 5A
Supply Voltage 10.5 - 31.2 VDC (12/24V systems)
Operating Temperature Range -25° to + 55°C (-13° to +130°F)
Waterproof Rating IPX6
MFD Dimensions 510mm (20")
Physical Dimensions 510mm dia x 223 mm H. (20" dia x 8.8" H)
Weight 5.9 kg (13 lbs) without cable
Radar Beam Width 4.9° H x 25° V
Max Range, scale 24 NM
Max Operating Wind Speed 100 knots (51 m/s)
Min Range, scale 50 m / 200 ft / 50 yd
Radar Modes Harbour, Offshore, Weather, North Up, Course Up, Relative motion, True Motion
Radar Technology Pulse Compression
Rotation Speed 24 RPM
Warranty Period 2 Years
Interface Simrad MFD

Warranty

2 Years

Price

Contact us for pricing

Item/ Product Code

000-14537-001

GTIN

N/A

Weight

5.9 kg (13 lbs) without cable

SEO Meta Keywords

eMarine, SIMRAD, HALO20 Radar, pulse-compression, target tracking, situational awareness, on-water safety, compact dome radar, MARPA, instant wake-up, easy operation, low power consumption, guard zones

SKU SIM000-14536-001
Barcode # 000-14536-001
Brand Simrad

2 Year Manufacturer Warranty
